chúng tôi cung cấp dịch vụ giải pháp một cửa, từ các mô-đun truyền thông, ăng-ten, PCB, PCBA và tất cả các thành phần cho PCB Bom.
|
Thông tin chi tiết sản phẩm:
Thanh toán:
|
| Packaging Type: | Reel Tray Tube Tape Bag | Operating Temperature: | -40°C ~ 125°C |
|---|---|---|---|
| Package / Case: | WSON-8 | Mounting Type: | SMD/SMT |
| Manufacturing Date Code: | 2024+ | Function: | Step-Down |
LM3410YSD
Features
• Qualified for Automotive Applications
• AEC-Q100 Test Guidance With the Following:– Device Temperature Grade 1:–40°C to 125°C Ambient Operating Temperature Range– Device HBM ESD Classification Level 2– Device CDM ESD Classification Level C6
• Space-Saving SOT-23 and WSON Packages
• Input Voltage From 2.7 V to 5.5 V
• Output Voltage From 3 V to 24 V
• 2.8-A (Typical) Switch Current Limit
• High Switching Frequency– 525KHz(LM3410Y)– 1.6 MHz (LM3410X)
• 170-mΩ NMOSSwitch
• 190-mV Internal Voltage Reference
• Internal Soft Start
• Current-Mode, PWM Operation
• Thermal Shutdown
Applications
• LEDBacklight Current Sources
• LiIon Backlight OLED and HB LED Drivers
• Handheld Devices
• LEDFlash Drivers
• Automotive Applications
Description
The LM3410 and LM3410-Q1 constant current LED driver are a monolithic, high frequency, PWM DC-DC converter, available in 6-pin WSON, 8-pin MSOP PowerPad™, and 5-pin SOT-23 packages. With a minimum of external components the LM3410 and LM3410-Q1 are easy to use. It can drive 2.8-A (typical) peak currents with an internal 170-mΩ NMOS switch. Switching frequency is internally set to either 525 kHz or 1.6 MHz, allowing the use of extremely small surface mount inductors and chip capacitors. Even though the operating frequency is high, efficiencies up to 88% are easy to achieve. External shutdown is included, featuring an ultra-low standby current of 80 nA. The LM3410 and LM3410 Q1 use current-mode control and internal compensation to provide high-performance over a wide range of operating conditions. Additional features include PWM dimming, cycle-by-cycle current limit, and thermal shutdown.
Information
|
Category
|
|
|
|
Manufacturer
|
Texas Instruments
|
|
|
Series
|
-
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel
|
|
|
Part Status
|
Active
|
|
|
Type
|
DC DC Regulator
|
|
|
Topology
|
SEPIC, Step-Up (Boost)
|
|
|
Internal Switch(s)
|
Yes
|
|
|
Number of Outputs
|
1
|
|
|
Voltage - Supply (Min)
|
2.7V
|
|
|
Voltage - Supply (Max)
|
5.5V
|
|
|
Voltage - Output
|
3V ~ 24V
|
|
|
Current - Output / Channel
|
2.8A (Switch)
|
|
|
Frequency
|
525kHz
|
|
|
Dimming
|
PWM
|
|
|
Applications
|
Backlight
|
|
|
Operating Temperature
|
-40°C ~ 125°C (TJ)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
6-WDFN Exposed Pad
|
|
|
Supplier Device Package
|
6-WSON (3x3)
|
|
|
Base Product Number
|
Drawing
Our advantage :
be sure to meet your need for all kinds of components. ^_^
Product List
Supply a Series of Electronic Components, full range of semiconductors, active & passive Components.We can help you to get all for bom of the PCB,IN a word, you can get one-stop solution here,
The offers including:
Integrated Circuit, Memory ICs, Diode, Transistor , Capacitor, Resistor, Varistor, Fuse, Trimmer & Potentiometer, Transformer, Battery, Cable, Relay, Switch, Connector, Terminal Block, Crystal & Oscillator, Inductor, Sensor, Transformer, IGBT Driver, LED,LCD, Convertor, PCB (Printed Circuit Board),PCBA (PCB Assembly)
Strong in Brand:
Microchip, MAX, AD, TI, ATMEL, ST, ON, NS, Intersil, Winbond, Vishay, ISSI, Infineon, NEC, FAIRCHILD, OMRON,YAGEO, TDK, etc
Người liên hệ: Mrs. Natasha
Tel: 86-13723770752
Fax: 86-755-82815220
